Input parameter files¶

FOXES can run from YAML parameter files through the foxes_yaml and foxes_windio command-line tools.

foxes_yaml¶

Command and options¶

The command line tool foxes_yaml accepts input yaml files that follow a foxes specific structure, that will be described shortly. A file with the name inputs.yaml can then be run in a terminal by

foxes_yaml inputs.yaml

If the parameter file is located elsewhere, relative input paths are resolved from its parent directory. For example,

foxes_yaml path/to/inputs.yaml

resolves relative input paths from path/to/. Absolute paths are unchanged.

The foxes_yaml command has multiple options, which can be checked by

foxes_yaml -h

For example, it is possible to everrule the rotor_model choice of the inputs.yaml file by the model choice grid25, by

foxes_yaml inputs.yaml -r grid25

Also engine choices can be overruled, for example by

foxes_yaml inputs.yaml -e process -n 8

for enforcing a parallel run on 8 processors using the ProcessEngine.

If you wish to modify the default output directory, you can do so by

foxes_yaml inputs.yaml -o results

which sets results as the output base directory for relative output paths.

Input file structure¶

The structure of foxes yaml files is very close to the foxes code base. Let’s look at an example, available here in the foxes repository:

states:
  states_type: Timeseries               # class from foxes.input.states
  data_source: timeseries_8000.csv.gz   # specify constructor arguments here
  output_vars: [WS, WD, TI, RHO]
  var2col:
    WS: ws
    WD: wd
    TI: ti
  fixed_vars:
    RHO: 1.225

model_book:                 # this section is optional
  turbine_types:            # name of the model book section to be updated
    - name: my_turbine      # name of the new model
      ttype_type: PCtFile   # class from foxes.models.turbine_types
      data_source: NREL-5MW-D126-H90.csv # specify constructor arguments here

wind_farm:
  layouts:    # list functions from foxes.input.farm_layout below
    - function: add_from_file
      file_path: test_farm_67.csv
      turbine_models: [my_turbine]

algorithm:
  algo_type: Downwind
  wake_models: [Bastankhah2014_linear_k004]

calc_farm:    # this section is optional; will run by default
  run: True   # this triggers algo.calc_farm

outputs:                          # this section is optional
  - output_type: FarmResultsEval  # class from foxes.output
    functions:                    # list of functions from that class below
      - function: add_capacity
      - function: add_efficiency
  - output_type: StateTurbineMap  # class from foxes.output
    functions:                    # list of functions from that class below
      - function: plot_map        # name of the function
        variable: "EFF"           # specify function parameters here
        cmap: "inferno"
        figsize: [6, 7]
  - output_type: plt              # class from foxes.output
    functions:                    # list of functions from that class below
      - function: show            # runs plt.show(), triggering the display
      - function: close           # runs plt.close(), optional

Any of the applicable foxes classes and functions can be added to the respective section of the input yaml file, together with the specific parameter choices.

Output evaluation¶

The outputs section can call FOXES output classes, including FarmResultsEval for reductions, efficiency, capacity, and yield. See the output API for available methods and arguments. Calculations that need Python objects such as the algorithm are usually clearer in a script or notebook.

Plot creation and variables¶

Function results can be stored under names beginning with $ and passed to later calls. Use object: $name to call methods on a stored object; array-like results also support index expressions such as $data[0]. See the combined-plot example for a complete workflow.

foxes_windio¶

FOXES currently reads the schema from the EUFLOW windIO fork. Install its parser with:

pip install git+https://github.com/EUFLOW/windIO@master#egg=windIO

Run a WindIO file with:

foxes_windio path/to/windio_input.yaml

Use the example under examples/windio as the supported input reference. An explicit FOXES wake_averaging setting takes precedence over inferred WindIO rotor-averaging choices.

Enabled WindIO blockage models automatically select the iterative algorithm and ground_mirror for their induction wakes. This applies to RankineHalfBody, Rathmann, SelfSimilarityDeficit, and SelfSimilarityDeficit2020. Selecting None or none leaves blockage disabled. TurbOPark wind deficits also enable ground mirroring; other per-wake ground settings remain unchanged.

List all command options with:

foxes_windio -h
